L-1DVI-FE-TX/RX

1 Channel DVI Over Fiber Transmitter and Receiver Kit

Tech Specs
Application Drawing
Features

The QuestTel L-1DVI-FE-TX/RX Fiber Optic Transmitter and Receiver provides long haul transmission of high resolution DVI signals over a single fiber up to 20km. Engineered for reliability and exceptional high resolution image performance, it uses QuestTel technology to deliver perfect pixel-for-pixel transmission of computer-video images up to 1920x1080@60Hz resolution. The compact, low profile enclosure of the L-1DVI-FE-TX/RX allows for discreet installation. It can be used for simple point-to-point applications or handle the most challenging AV system designs, from a simple conference room to an enterprise-wide fiber optic distribution system.
The L-1DVI-FE-TX/RX Transmitter and Receiver is ideal for a wide range of applications requiring long distance transmission of high resolution content with the highest quality. Because transmission of content is inherently secure and immune to outside interference, fiber applications are favored in government, military, and medical environments. The transmitter features industry standard SC-type Optical Connector.

QuestTel L-1DVI-FE-TX/RX supports multimode and singlemode transmission. Singlemode fiber offers long-range transmission capability over extreme distances of up to 20 km (12 miles). It is used in very large facilities such as airports, stadiums, live broadcast signal transmission, remote studio, universal digital video transmission business, telecommunication signal transmission business, airport or transportation hubs as well as connecting over very long distances between facilities such as college campuses.

Contact us

1 Channel DVI Over Fiber Transmitter and Receiver Kit

Request a Quote:

Send an Enquiry
Features
    • Supports Singlemode and Multimode transmission
    • Transmission distance up to 20Km over Single Mode Fiber
    • Transmission distance up 500m over Multimode Fiber
    • Resolution supported is up to 1920x1080@60Hz.
    • Support RS232 Bi-directional pass back .
    • Avoid the electromagnetic interference in environment for long distance transmission.
    • Low signal loss, wide frequency band and strong anti-interference.
    • Plug and play.
    • Wall-mountable design, easy for installation.
Tech Specs
L-1DVI-FE-TX/RX
DVI Signal format  DVI-D 1.0
DVI type  DVI-D
Network Cable  Support SMF and MMF cables
Transmission distance

 Up to 20Km over Single Mode Fiber

 Up 500m over Multimode Fiber

Support Resolutions
 800x600@60Hz, 1024x768@60Hz, 1280x720@60Hz

 1280x960@60Hz, 1366x768@60Hz, 1440x900@60Hz

 1680x1050@60Hz, 1920x1080@60Hz

Working Temperature  0°C ~ 60°C
Power Supply  5V/1A*2pcs
Product Dimensions   177.5(L)x105(W)x23(H)mm
Weight  TX:400g    RX:400g



L-1DVI-FE-TX-RX DVI Over Fiber  Pdf User Manual: L-1DVI-FE-TX-RX



Disclaimer: Products, specifications and data are subject to change without notice, to improve reliability, function, design or otherwise.

QuestTel shall have no liability for any error or damage of any kind resulting from the use of this document.
Application Drawing 1 Channel DVI Over Fiber Transmitter and Receiver Kit's Application Drawing
